GFEVT1000-38R High speed fuse（250A-400A）1000Vdc

[附件: Download]

Specifications

Ratings & Features Applications :
 Volts: 1000 Vdc;
 Amps: 250A-400A;
 Interrupting Capacity :
Rated Breaking Capacity：50 kA;
Min BC ≥ 3.0 In;
Time Constant：≤5 ms;
Type：aR
 Design For Dc Applications ;
 Excellent Dc Performance ;
 Electrical Energy Storage ；

 Battery Pack Protection ；

Standards / Approvals :
 Refer To IEC 60269.4/UL 248.13/JASO-D622
IEC 60269.4/UL 248.13/JASO-D622；
 Reach Declaration Available Upon Request;

 RoHS Compliant.
RoHS。
Standards / Approvals :
 Refer To IEC 60269.4/UL 248.13/JASO-D622
IEC 60269.4/UL 248.13/JASO-D622；
 Reach Declaration Available Upon Request;

 RoHS Compliant.
RoHS。
